GML-1790T,, 17” x 90”, 3-1/8” bore - With free CARMAR DRO installed
Machine Standard Features and Equipment:
- Free CARMAR DRO, installed
- Automatic kick-out longitudinal carriage stop system
- 10” 3-jaw chuck with top reversible jaws, direct mount
- 16” Face plate
- 9” steady rest with roller jaws
- 4” follow rest with roller jaws
- Removeable gap
- 4-way tools post
- Foot brake
- LED Work light
- coolant system
- full length rear splash guard
- Dead centers
- Thread chasing dial
- Reducing sleeve MT6/MT5 for spindle
- Tool box and leveling pads
Standard Equipment:
- Free CARMAR DRO, installed
- Automatic kick-out longitudinal carriage stop system
- 10” 3-jaw chuck with top reversible jaws, direct mount
- 16” Face plate
- 9” steady rest with roller jaws
- 4” follow rest with roller jaws
- Removeable gap
- 4-way tools post
- Foot brake
- LED Work light
- coolant system
- full length rear splash guard
- Dead centers
- Thread chasing dial
- Reducing sleeve MT6/MT5 for spindle
- Tool box and leveling pads
Optional:
- Taper attachment, installed ……………………………………… $2,950.00
- 5-C Hand lever type collet closer, free install ....………………... $2,250.00
- 33 pc 5C collet set, from 1/16”-1-1/16” by 32nd, Part# 3900-0014.. $595.00
- ALORIS type QC tool post set # 3900-5260, 6 pcs …,,,,,,,,,,,,,,,,,,,…..,..$975.00
- Live Center # 3900-5004 for tailstock ............................................... $265.00
- Live Center # 3900-5005 for headstock ............................................... $295.00
- Chuck guard …………………………………………………………….$795.00
Specifications:
|
Specifications |
GML-1760T |
GML-1790T |
|
Max. swing over bed |
17” |
17” |
|
Max. length of workpiece |
60” |
90” |
|
Max. swing over cross slide |
9-1/2” |
9-1/2” |
|
Max. Swing in gap |
25-1/2” |
25-1/2” |
|
Width of Bed |
12” |
12” |
|
Effective length in gap to spindle |
6” |
6” |
|
Effective length in gap to chuck jaws |
3-1/2” |
3-1/2” |
|
Spindle bore |
3-1/8” , D1-8 |
3-1/8” , D1-8 |
|
Taper of spindle center |
M.T.# 6 w/ reducing sleeve MT6/MT5 |
M.T.# 6 w/ reducing sleeve MT6/MT5 |
|
Spindle speeds |
40-2,000 rpm / 12 steps |
40-2,000 rpm / 12 steps |
|
Longitudinal feeds |
0.002-0.03 IPR, 35 kinds |
0.002-0.03 IPR, 35 kinds |
|
Cross feeds |
0.0008-0.011 IPR, 35 kinds |
0.0008-0.011 IPR, 35 kinds |
|
Inch threads |
4-56 TPI, 36 kinds |
4-56 TPI, 36 kinds |
|
Metric threads |
0.5-7.0 mm ,17 kinds |
0.5-7.0 mm ,17 kinds |
|
Max. travel of top slide |
5” |
5” |
|
Max. travel of cross slide |
11” |
11” |
|
Spindle length w/o chuck |
17” |
17” |
|
Leadscrew length X TPI |
1-1/4” x 4 TPI |
1-1/4” x 4 TPI |
|
Diameter of tailstock quill |
2-3/4” |
2-3/4” |
|
Max. travel of tailstock quill |
5-7/8” |
5-7/8” |
|
Taper of tailstock quill center |
M.T. #4 |
M.T. #4 |
|
Main motor |
7-1/2HP, 220V or 440V, 3 phase |
7-1/2HP, 220V or 440V, 3 phase |
|
Amperage Draw |
220V/ 35A , 440V/20A |
220V/ 35A , 440V/20A |
|
Coolant pump motor |
1/8 HP, 220V, or 440V, 3 phase, 2Gal coolant |
1/8 HP, 220V, or 440V, 3 phase, 2Gal coolant |
|
Machine Oil |
# 30 weight Machine oil, 5 Gallons |
# 30 weight Machine oil, 5 Gallons |
|
Machine weight, approx. LBS |
3,950 LBS |
4,750 LBS |
|
Overall dimensions, LxWxH Shipping dimensions: LxWxH |
105” x 41” x 57” 110” x 38” x 63” |
139” x 41” x 57” 140” x 38” x 63” |
|
|
